Having 10+ years experiences focusing on lighting PCBs, Fast PCB Studio proudly defines itself the best sourcing partner for customers seeking Small/Medium Volume & Very Fast supplies.

ABOUT US

Fast PCB Studio Co. LTD is an ISO/UL certified LED PCB & MCPCB specialized PCB manufacturer.

The products including high heat dissipation 1-2 layer Aluminum & Copper Core PCB, and 1-8 layers FR4 PCB prototype & mass production for fast supply.

The products are widely used in Street lights, Lawn lamp, Tube lights,  Panel lights, Spotlights, Downlights, Commercial lights, Home lights, Energy saving lights and etc.

Our Products

We are the highly specialized in lighting industry and produce the most cost effective & reliable Aluminum PCB & Copper Core PCB that you are looking for.

LED Lighting PCBs (High Thermal Conductivity)

Board Thickness:0.5 – 4MM
Copper Thickness: 1-4OZ

LED tube PCBs ​

Board Thickness:1-1.6MM
Copper Thickness: 0.5/1/2 Oz

LED Bulb PCBs

Board Thickness:1-1.6MM
Copper Thickness: 1-2OZ

The place where you’ll get the perfect solution for all your LED PCB needs.

Technical Capability

Technical

 Object

Capability & specification

Material

Aluminum substrate / copper substrate / copper aluminum composite plate /FR-4

Thermal conductivity

1.0W/1.5W/2.0W/122W

Thickness

0.3~5.0MM

Surface Finishing

Lead-free HASL / Immersion Gold /OSP

Max. Panel size

1500*500MM

Min. Panel size

5*5MM

Min line width

0.25MM (10mil)

Min line gap

0.25MM (10mil)

Minimum aperture

∮1.6mm

E-T Test

100% Automated short circuit test

Technical

Object

Capability & specification

Plate warp rate

<=0.5% (350*350mm)

Withstand voltage

AC1500-4000V

Copper Foil Thickness

18um / 35um / 70um / 105um

Molding method

CNC /Die punching/ V-CUT

External tolerance

CNC: ±0.1~0.15MM

Die punching:±0.125MM

Type of resistance welding

White or customized

Production process

Exposure process

Monthly capacity

20000 square meters

Lead Time

Sample: 2-4 days / batch: 1~3 weeks.

Fast LED & Metal Core PCB supply

Our Advantages

  • ​24 hours production time for 1-2 layer PCB
  • 48 hours for 4 layers / MC PCB
  • 72 hours for 6 layers​​
  • ​A transparent & fixed price guideline to help the customer knowing the cost immediately
  • Punctuality on Lead Time given (96% productions delivered to the customers on time)

Closely work with Aluminum PCB & Metal Core PCB raw material manufacturing plants in the inner cities of China to provide the customers the more cost effective solution.

  • ​UL & ISO Certified
  • Reliable white solder mask ink brands with rich experiences on lighting PCB manufacturing to avoid color tone change into yellow after re-flow soldering
  • ​Strictly follow the original design to make sure the boards meeting all testing criteria
